48V Phantom Supply on 4 Channels With Built-in MP3 Player
AC Operation with Digital Effects
- 8 x Balanced Mono Inputs. 1 x Balanced Stereo Input. XLR sockets for all Mic Inputs. Digital Effects with Delay, Repeat and Level controls. Built-in MP3 player with USB, SD/MMC Card reader and Bluetooth playback facility. Phantom Supply available on 4 channels.
- Ahuja introduces a high performance Professional PA Mixer PMX-1032DFX, which has 8 MIC/LINE input channels, 1 Stereo input channel and built in MP3 player. It is designed for exceptional sound quality & superior reliability in both monitoring and live sound applications
- Rugged, reliable, high quality analog mixer with user-friendly construction & aesthetically designed side panels.
- Eight MIC/LINE Balanced Mono inputs with enhanced headroom.
- One STEREO Balanced input in two selectable sensitivities of -10dBu & +4dBu.
- Built-in MP3 player with USB, SD/MMC card reader and Bluetooth.
MIC INPUT
.
Impedance/Gain
2kΩ Balanced/65dB
LINE INPUT
.
Impedance/Gain
20kΩ Balanced/45dB
STEREO INPUT (L/Mono & R)
.
Impedance/Gain (-10dBu Input)
10kΩ Balanced/14dB
Impedance/Gain (+4dBu Input)
10kΩ Balanced/0dB
THD
<0.08%
FREQUENCY RESPONSE
25Hz - 20kHz (+0, -1dB)
EQUALIZATION
.
Bass/Mid/Treble
±12dB at 100Hz/2kHz/10kHz
CLIP LED INDICATION
4 dB prior to true clip
LINE OUTPUT
.
Nominal/Max Level
4dBu/21dBu (1.22V/9V)
IMPEDANCE
600Ω
DELAY SYSTEM
Digital Signal Processing
DELAY RANGE SETTINGS
1: 60-300ms, 2: 300-500ms, 3: 500-650ms Variable from 20 to 300ms
DIGITAL PLAYER
MP3 Player with USB, SD and MMC Card Reader
HEADPHONE OUTPUT
200mV at 8Ω, THD <1%
MAXIMUM GAIN
.
Mic Input to Line Outputs
78dB
Line Input to Line Outputs
58dB
Stereo Input to Line Outputs
28dB (-10dBu Input) 14dB (+4dBu Input)
AUX Send (Pre)
1.4V/100Ω Unbalanced
AUX Send (Post)
2.7V/100Ω Unbalanced
AUX Return (L&R)
150mV/10kΩ Balanced
Record Output (L&R)
250mV/600Ω
Playback Input (L&R)
250mV/1kΩ (variable through GAIN control)
SIGNAL TO NOISE RATIO
>70dB
POWER SUPPLY
AC: 220-240V, 50Hz
DIMENSIONS
W465 × H110 × D435 mm
WEIGHT
7.70kg
